ARCHILIFT D400

Hinged access cover with locking system and key

ArticulaciónBloqueo antiretornoCerraduraMarco cuadradoResorte de torsionSoporte elastico

Material

Casting manufactured in spheroidal-graphite cast iron (ductile cast iron) in accordance with the EN-1563 Standard.

Features

Access cover of 760x760mm clear opening. Hinged cover with maximum opening range of 110º. Hinge with spring system for easy handling. Cover includes a hermetic gasket and has an anti-slip surface especially designed with a slight slope so that water is eliminated quickly. Anti-theft closing system and lifting key included. The typical usage of this product is for accesses to the carburant deposits in petrol stations. Customization available.

Coating

Epoxy-polyester with a thickness of 100 microns, free of solvents compliant with the standard 199/13/CEE, black RAL-9004.

ModelCover dimensions (a) mmFrame dimensions (b) mmFrame height (h) mmClear opening (o) mmCertificatesTechnical information
3193 *840x8401015x920100760x760BVC
* ergonomic lifting key with long handle, customizable with an adapted head, usable as a grip for opening and closing.
Request advice. Our engineering dept. will study your project
to propose the best solution. Call us +34 938 034 697
